BABY MONITOR BM-385
Click:
  BM-385
1.5 inch TFT Baby Montor Kit
Feature:
Palm size monitor for mobility
4X AAA Rechargeable NiMH Battery or 6V DC adaptor
High quality Color CMOS sensor for crisp,clear images
Built-in microphone for audio monitoring
Have 8 Infra-red LED on the camera for Nightvision (Day & Night Uses)
3-channel operation allows multiple (1-3) camera system
380TV lines sharp picture display.
Long operation range:up to 100M clear line-of-sight or 30M through obstructions (walls/ceilings)
Ideal for Baby/Children Room Monitoring


    Description:

Monitor Specification Camera Specification Standard Package Content
Frequency:ISM 2,400 - 2,483MHz
Channel:3 selectable channels
CMOS Total Pixels :628x582(PAL)510x492(NTSC)
Display:1.5" LTPS-TFT LCD
Demodulation Mode:FM
Display colors :Full- color
Power:DC 6V DV,500mA or 4 AAA-size batteries
Antenna:Built-in omni-directional antenna
Dimension(WxLxH):50x80x120 mm
Weight:150g
Frequency:ISM 2,400 - 2,483MHz
Imaging Sensor:1/3 inch OMNIVISION Color CMOS
Horizontal Resolution:380TV Line
CMOS Total Pixels:628 x 582 (PAL) / 510 x 492 (NTSC)
View Angles:62 degrees
Minimum Illumination:1.5Lux / F1.5
Gain Control:Automatic
Transmission Power:10mW
Modulation Mode:FM
Antenna:Built-in omni-directional antenna
Lens:f6.0mm F 1.8
Dimension(WxLxH):55x80x280mm( Unbends )
Weight:130g
2.4GHz Wireless"WATCHDOG" Nightvision Camera
2.4GHz Wireless 3-channel LCD Receiver
A/V Cable
6V Power Adaptor for Camera
Earphone
6V Power Adaptor for LCD Receiver
