| Model No.:
EVP438-2WCO |
 |
Color Video Doorphone
Tube:4 inch flat tube CCIR or EIR　
TV system:15.75Khz (H) 60Hz(V)　
Resolution:420 Line　
Call Signal Sound:Chime Sound (Ding-Dong, Bell)　
Telephone System:2 Wires　
Auto Iris:Internal ALC System　
Power Supply:AC230V/50HZ or 120V/60HZ　
Wiring Distance:50 M　
CCD:1
|
  |
|
| Model No.:
EVP438-COL |
 |
Video Doorphone
Tube:4 inch flat tube ( COLOR ) CCIR or EIR　
TV system:15.75Khz (H) 60Hz(V)　
Resolution:420 Line　
Call Signal Sound:Chime Sound (Ding-Dong, Bell)　
Telephone System:4 Wire　
Auto Iris:Internal ALC System　
Power Supply:AC230V/50HZ or 120V/60HZ　
Wiring Distance:50 M　
|
|
|
|
| Model No.:
EVP438-BW |
 |
Video Doorphone
Tube:4 inch flat tube (B/W) CCIR or EIR　
TV system:15.75Khz (H) 60Hz(V)　
Resolution:420 Line　
Call Signal Sound:Chime Sound (Ding-Dong, Bell)　
Telephone System:4 Wire　
Auto Iris:Internal ALC System　
Power Supply:AC230V/50HZ or 120V/60HZ　
Wiring Distance:50 M　
|
|
|
|
| Model No.:
EVP438A-COL |
 |
Outdoor bell Specification
Power source:DC 12V supplied by indoor phone　
Camera:CCD (CMOS optional)　
Illumination:0.5 LUX　
Light source:6 infrared LEDs　
Power consumption:Max. 6.8W, standby 3W　
Operating temperature:-25oC～75oC　
Installation:Wall-mount/flush　
Indoor phone Specification:
|
|
|
|
| Model No.:
EVP438A-BW |
 |
Indoor monitor
Power Source:DC 14V　
Power Consumption:12W　
Display:4" Flat CRT Tube　
Chime:Ding Dong Chime　
Communication:dual- way　
Resolution:380 lines　
Operating temperature:-25oC～75oC　
Installation:wall- mounted　
Outdoor station:plastic material　
Power Source:AC10
|
|
|
|
| Model No.:
EVP-238-2WCO |
 |
Color Video Doorphone
Tube:4 inch flat tube CCIR or EIR　
TV system:15.75Khz (H) 60Hz(V)　
Resolution:420 Line　
Call Signal Sound:Chime Sound (Ding-Dong, Bell)　
Telephone System:2 Wires　
Auto Iris:Internal ALC System　
Power Supply:AC230V/50HZ or 120V/60HZ　
Wiring Distance:50 M　
CCD:1
|
|
|
|
| Model No.:
EVP-228MCF |
 |
Four wires color video and audio doorphone
Power course:AC 110~240V　
Wait Consume :<0.5W　
Oeration Consume :<=10W　
Oeration temperature :-15~50
Screen :3.5" TFT LCD　
Effective resolution :480(H)*234(V)　
External dimension :
Monitor:225(L)*190(W)*62(H)mm　
Camera:160(L)*70(W)*26(H)mm　
Phone:210(L
|
|
|
|
| Model No.:
EVP-278S-COL |
 |
Four wires Handfree color video doorphone
Power course:DC 16V　
Wait Consume:<0.5W　
Oeration Consume:<10W　
Oeration temperature:-15~50
Screen:3.5"/5" TFT LCD　
Effective resolution:
480(H)*234(V) or 960(H))*234(V)　
External dimension:
Monitor:185(L)*130(W)*27(H)mm　
Camera:127(L)*95(W)*35(H)mm　
|
|
|
|
| Model No.:
EVP-298C-2WM |
 |
Two wire hand free color video doorphone
Power course:DC 16V　
Wait Consume:<0.5W　
Oeration Consume:<10W　
Oeration temperature:-15°C→+50°C　
Screen:3.5"/5" TFT LCD　
Effective resolution:480(H)*234(V) or 960(H))*234(V)　
External dimension:
Monitor:185(L)*130(W)*27(H)mm　
Camera:132(L)*80(W)*22.4
|
|
|
|
| Model No.:
EVP-129 |
 |
Video DoorPhone
Power course:AC 110V~240V　
Operation temperature:-15~50
External dimension:
Monitor :210(L)*79(W)*45(H)mm　
Camera :160(L)*70(W)*26(H)mm　
Installation:surface-mount　
Match way:one to one　
Connection:3 wire
|
|
|
|
| Model No.:
EVP-228-COL |
 |
Four wires surface-mount color video doorphone
Power course:DC 16V　
Wait Consume :<0.5W　
Oeration Consume:<=10W　
Oeration temperature:-15~50　
Screen:3.5" TFT LCD　
Effective resolution:480(H)*234(V)　
External dimension:
Monitor:215(L)*212(W)*67(H)mm　
Camera:160(L)*70(W)*26(H)mm　
Installation:surfa
|
|
|
|
| Model No.:
EVP-295-COL |
 |
Four Wires hand free color video doorphone
Power course:DC 16V　
Wait Consume / Oeration Consume:<0.5W /<=10W　
Oeration temperature:-15~50 Screen:3.5" TFT LCD　
Effective resolution:480(H)*234(V)　
External dimension:
Monitor:225(L)*170(W)*52(H)mm　
Camera:127(L)*95(W)*35(H)mm　
Installation:surface-mountã€
|
|
|
|
|
|
|
|
