| Model No.:
SS-072
|
 |
Alarm Switch
Product No.:SS-072
Dimensions:2 3/4" L*1 1/16" W*5/8" H(70mm L*28mm W*16mm H)
Weight:.6 oz.(18g)
Functionality:Plunger in:contact closed:plunger released:contact open
Contact Rating:0.5Aat50V DC
Materials:High-impact plastic resin case:silver-plated contact
|
  |
|
| Model No.:
EEB-502
|
 |
Emergency Button
Terminal:3P Normality Open NO
Rating:AC125V 3A 250V 1A
Dielectric Strength:AC 1000V 1 minute
Contact R.:More than 100M OHM at DC500V
Insulation Resistance:Less than 2100M OHM
Electrical Life:More than 20,000 time
Remark:CE
|
|
|
|
| Model No.:
EPB-01 |
 |
Push Button
Type:Push Button
Terminal :COM.,N/O
Rating:VDC250/ 300mA
Dielectric Strength:AC 1000V 1 minute
Contact R.:More than 100M OHM at DC500V
Insulation Resistance:Less than 2100M OHM
Electrical Life:More than 20,000 time
Remark:Holdup Button 53.6*53.6mm
|
|
|
|
| Model No.:
EEB-501 |
 |
Emergency Button
Terminal:2P Normality Open NO
Rating:AC125V 3A 250V 1A
Dielectric Strength:AC 1000V 1 minute
Contact R.:More than 100M OHM at DC500V
Insulation Resistance:Less than 2100M OHM
Electrical Life:More than 20,000 time
Remark:CE
|
|
|
|
| Model No.:
EPB-02A |
 |
ABS Plastic or case body
Contact Mode:COM.,N/O
Rated current:300
Rated Voltage(VDC):250
G.W.(kgs):12.5
QTY(pcs):180
Meas:(mm) 540*360*270
|
|
|
|
| Model No.:
EFB-012
|
 |
Metal Case
Contact Mode:COM.,N/O
Rated current:3000
Rated Voltage (VDC):250
G.W.(kgs):13
QTY(pcs):10
Meas:(mm) 570*395*320
|
|
|
|
| Model No.:
EPB-01C |
 |
ABS Plastic Housing
Contact Mode:COM.,N/O
Rated current:300(mA)
Rated Voltage (VDC):250
G.W.(kgs):12
QTY(pcs):160
Meas:(mm) 370*370*380
|
|
|
|
| Model No.:
EPB-01D |
 |
ABS Plastic Housing
Contact Mode:COM.,N/O
Rated current:300(mA)
Rated Voltage (VDC):250
G.W.(kgs):12
QTY(pcs):160
Meas:(mm) 370*370*380
|
|
|
|
| Model No.:
EPB-01B |
 |
ABS Plastic Housing
Contact Mode:COM.,N/O
Rated current:300(mA)
Rated Voltage:(VDC) 250
G.W.(kgs):13
QTY(pcs):160
Meas:(mm) 370*370*380
|
|
|
|
| Model No.:
EPB-01A |
 |
ABS Plastic Housing
Contact Mode:COM.,N/O
Rated current:300(mA)
Rated Voltage:(VDC) 250
G.W.(kgs):12
QTY(pcs):160
Meas:(mm) 370*370*380
|
|
|
|
| Model No.:
278 |
 |
Alarm Switch
Rating:2.5A 250VAC
Contact Resistance:<=50m
Insulation Resistance:>=100M
Dielectric intensity::>=1500VAC/1min
Life:>=10000 Cycles
|
|
|
|
| Model No.:
7-9 |
 |
Alarm Switch
micro-switch is suitable for using in each kind of control circuit with the rated voltage less than 250vand rated current less than 20A (DC and AC effective value)for controlling elements,it is the sense switch with the certain movement strength through the certain trave ling to cause the electronic
|
|
|
|
|
|
|
|
