| Model No.:
DPS28A
|
 |
PIR motion sensor
2-5m(adjustable)(max-8m)(<22°C)
120°sideview) x 360° topview)
5-480 sec (adjustable)
1200W (220~230V/AC) | 3000w (220~230V/AC)
90~130V/AC | 180~250V/AC | 90~250V/AC(thru)
50-60HZ
49x34x35cm (60pcs)
17/12KG
|
  |
|
| Model No.:
DPS28B
|
|
|
Ceiling Mount Occupancy Sensors
Power source:220V/AC-240V/AC 100V/AC-130V/AC
Power frequency:50~60Hz
Ambient light:<3LUX-daylight
Time-delay:min:8+/-3sec max:7+/-2min
Rated load:1200W (220-240V/AC) 800W (110V/AC)
3000W(220-240V/AC) 1500W (110V/AC)
Detection motion speed:0.6-1.5m/s
Det
|
|
|
|
| Model No.:
DPS21B |
 |
PIR Sensor
>8m (<22oC)
140° 180° size=
5-450 sec (adjustable)
1200W (220~230V/AC)
110~130V/AC | 220~250V/AC | 90~250V/AC(thru)
50-60HZ
36.5x34x37.5cm (120pcs)
17/11KG
|
|
|
|
| Model No.:
DPS21C
|
|
|
Passive Infrared (PIR) Sensor
WallMounted Activated Light Control with Switch
Sensor Distance:>8m(<22oC)
Sensor range:140° or 180°
Time:5-450 sec (adjustable)
Power:1200W (220~230V/AC)
Volt. AC:1. 90~130V/AC 2. 180~250V/AC
Operational Frequencies:50-60HZ
Relative Humidity:20% to 90%
|
|
|
|
| Model No.:
DPS20
|
 |
PIR Sensor
8m(max) (<22°C)
120° side view) x360° top view)
5-480 sec (adjustable)
1200W (220~230V/AC)
1. 90~130V/AC 2. 180~250V/AC 3. 90~250V/AC(thru)
50-60HZ
48.4x33.6x33.2cm (60pcs)
16/12K
|
|
|
|
| Model No.:
DPS22 |
 |
PIR Sensor
Power source: 100V/AC~277V/AC
Power frequency: 50~60Hz
Ambient light: 2~ 1000LUX(adjusted)
Time-delay: min:8s+/- 3s max:7min+/- 2min
Rated load: 500W(220V/AC~240V/AC)
Detection motion speed:0.6~1.5m/s
Detection range: 180 degree 140 degree
Detection distance: 9m max(
|
|
|
|
| Model No.:
DPS2000 |
 |
PIR Sensor
Power source:90V/AC~240V/AC
Power frequency:50~60Hz
Light-control:3LUX~1000lux (adjustable)
Time-delay:5sec~420sec(adjustable)
Rated load:300W (110V/AC) ~ 500W (220V/AC~240V/AC)
Detection motion speed:0.6~1.5m/s
Detection range:>140
Detection distance:12m max (<22 C
|
|
|
|
| Model No.:
DPS19C |
 |
PIR Sensor
9m(max)(<22oC)
120° size=
5-480 sec (adjustable)
200W (220V/AC)
90~130V/AC | 180~250V/AC
50-60HZ
40.5x27x46.5cm (60pcs)
16/12KG
|
|
|
|
| Model No.:
DPS118A |
 |
PIR Sensor
12m(max)(<22oC)
140°180° size=
5-480 sec (adjustable)
1200W(220V/AC)
90~130V/AC | 180~250V/AC | 90~250V/AC(thru)
50-60HZ
42*42*27cm (50pcs)
16/12KG
|
|
|
|
| Model No.:
DPS118B |
 |
PIR Sensor
Power source:220V/AC~240V/AC 110V/AC~240V/AC
Power frequency:50~60Hz 800W
Light-control:<3LUX~sunshine light
Working time: min: 8sec 3sec max: 7min 2min
Rated load:1200W (220V/AC~240V/AC) 800W (110V/AC~130V/AC)
3000W(220V/AC~240V/AC) 1500W(110V/AC~130V/AC)
Detection motion
|
|
|
|
| Model No.:
DPS48A |
 |
PIR Sensor
6m(low) 12m(high)(<22oC)
220° size=
5-540 sec (adjustable)
1200W(220V/AC)
90~130V/AC | 180~250V/AC | 90~230V/AC(thru)
50-60HZ
50x35x38cm (36pcs)
18/11KG
|
|
|
|
| Model No.:
DPS48B |
 |
PIR Sensor
6m(low) 12m(high)(<22oC)
270° size=
5-540 sec (adjustable)
1200W(220V/AC)
90~130V/AC | 180~250V/AC | 90~230V/AC(thru)
50-60HZ
47x43x29cm(50pcs)
16/12KG
|
|
|
|
|
|
|
|
