Security alarm cable,Fire alarm cable

Applications: Wiring Burglar & Security alarms, public address systems, intercoms, telephone stations, speakers, instrumentation, control and other low voltage circuits that are power limited.

Code Restrictions : OK for use with all (Non-Fire) power limited circuits except those in risers and plenums.

Features: Available in 500ft or 1000ft Tangle-Free Boxes or Spools. Sequential Footage Markings.

Construction: Copper Conductors, Genelene Insulation, Flexible Polyvinyl-Chloride jackets. Standard Jacket color: Gray. Conductor color code: Chart 1(up to 12 conductors), Chart 2 (13 Conductors and over).


    Features

  • Used as control cables
  • Conductor: 7 x 0.20mm tinned copper
  • Shielded or unshielded
  • 4C, 6C, 8C, 10C, 12C, 14C and 20C security alarm cables
  • Conductor: 0.6mm or 7 x 0.20mm plain annealed copper wire
  • Insulation: PVC flame retardant O.d. 1.0mm+/-0.05mm
  • Assembling: helicoidal under polyester tape
  • Shield: 7 x 0.20mm or 0.5mm copper drain wire, overall aluminium/polyester foil >100% coverage
  • Rip cord: red synthetic fibre
  • Outer jacket: PVC flame retardant in white with thickness of 0.7mm
  • Packing: 100m/box, or 100m/plastic spool, or 300m/wooden spool
