• PCB Terminal Block 125H-381
  • Click:
125H-381

PCB Terminal Block

3.50/3.81mm

  • Voltage rating:150VAC
  • Current rating:6Amps/way max.
  • Insulation resistance:5000M/1000V
  • Wire range:16-24AWG
  • Operation temperature:-33 to+120
  • Torque:2kg-cm/M2
  • cart
Description:
  • PCB Terminal Block
Contact:Brass Machined (metal housing) Terminal screw:Steel Galvanized and chormatized of Nickel plated or Tin plated (Standard option) Solder Pin:Brass with Tin plated Insulator body:Polyamide(Glass filled) (housing) (UL94V-0)
