DSW security mainly specilized in manufacuture of magnetic contact & switches,Recessed Magnetic Contacts,Magnet Recessed Switch,Steel Door Recessed Switch,Magnetic Sensors,Flanged Recessed Switch Sets,Ribbed Recessed Switch,Flat Magnetic,Door contact,Window Contacts. basket
Model No.: MCR-1301MD
Magnetic Contact MCR-1301MD

Recessed Mounted Contact

Type:Recessed Mounted Contact Type:Reed Switch / Open or Close Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:3/4 Inch Magnet:9.5*3.17 mm alno Lead Wire:#22 AWG 18 Housing:Recessed Mounted Dim:11mm * 32mm Listings:UL , CUL, CE Rem
Magnetic Contact MCR-1301MDMagnetic Contact MCR-1301MD
Model No.: MCR-1301
Recessed Mounted Magnetic Contact,Surface Mount Contact

Recessed Mounted Contact

Type:Recessed Mounted Contact Type:Roll Plunger Flush 360 Degree Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:0.25 Inch Magnet:Optional Lead Wire:AWG #22UL 1007 18 Inch Housing:Surface Mount with Special Adhensive Dim:39.6*39.6mm Listing
Magnetic Contact MCR-1301Magnetic Contact MCR-1301
Model No.: MCS-1203
Overhead Magnetic Contact,Surface Mount Contact

Overhead Door Contact

Type:Overhead Door Contact Contact Type:Closed Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:3 Inch Magnet: Lead Wire:Wire:#22AWG with 22 Armoured Cable Housing:Alum Case Dim:104.5*44.5MM Listings:CE,UL,CUL Remark:A:Open or C:Clo
Magnetic Contact MCS-1203Magnetic Contact MCS-1203
Model No.: MCS-3302
Surface Mount Contact,Surface Mount Switch

Surface Mount Contact

Contact Type:Reed Switch / Open or Close Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:1 1/4 Inch Magnet:14*12.3 mm Lead Wire:#22 AWG 18 Housing:Screw Mount ABS Dim:50 * 14mm Listings:UL , CUL, CE Remark:
Magnetic Contact MCS-3302Magnetic Contact MCS-3302
Model No.: MCS-2202
Magnetic Contact MCS-2202

Surface Mount Contact

Contact Type:Reed N/O Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:1.25 INCH Magnet:Optional Lead Wire:#22 AWG 18 Housing:ABS Screw Mount or Self Adhesive Dim:51MM *9 MM * 13.5MM Listings:UL , CUL, CE Remark:A:Open or C:Closed& Open
Magnetic Contact MCS-2202Magnetic Contact MCS-2202
Model No.: MCR-2101T
Magnetic Contact MCR-2101T

Recessed Mounted Contact

Contact Type:Reed Switch / Open or Close Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:1 Inch Magnet:Alnico 9.5*23L or 9.5*20L Lead Wire:AWG #22UL 1007 Housing:ABS Plastic Dim:24.5(Dia.) 0.965 Inch Listings:UL , CUL, CE Remark:B: SPD
Magnetic Contact MCR-2101TMagnetic Contact MCR-2101T
Model No.: MCS-4102
Magnetic Contact MCS-4102

Surface Mount

Contact Type:Open or Close Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:2.75 Inch Magnet:Optional Lead Wire:Screw Mount Housing:ABS Plastic Dim:14mm * 110mm Listings:UL , CUL, CE Remark:A: Open C: Closed & Open
Magnetic Contact MCS-4102Magnetic Contact MCS-4102
Model No.: MCR-3101
Magnetic Contact MCR-3101

Recessed Mounted Contact

Contact Type:Open or Close Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:1.25 Inch Magnet:Optional Lead Wire:UL#22 AWG 18 Housing:White ABS Plastic Dim:Dia9* 32MM Listings:UL ,CE Remark:A:Open C:Closed & Open
Magnetic Contact MCR-3101Magnetic Contact MCR-3101
Model No.: MCS-1102
Surface Mounted Magnetic Contact,Window security contacts

Surface Mounted Contact

Contact Type:Closed Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:1.125 Inch Magnet:Optional Lead Wire:AWG #22UL 1007 Housing:White ABS Plastic Dim:33.5*13.5*7.5MM Listings:UL ,CE,CUL Remark:A:Open C:Closed & Open
Magnetic Contact MCS-1102Magnetic Contact MCS-1102
Model No.: MCS-3102
Magnet contact Switch,door contact switch

Surface Mounted Contact

Contact Type:Closed Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:1.25 Inch Magnet:optional Lead Wire:Spacers, Cover and Screws Included Housing:White ,Brown ,Grey ABS Dim:65*19.2*5MM Listings:UL ,CE,CUL Remark:A:Open or C:Closed&
Magnetic Contact MCS-3102Magnetic Contact MCS-3102
Model No.: MCR-1101
Magnetic Contact MCR-1101

Recessed Mounted Contact

Contact Type:Closed Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:0.75Inch Magnet: Lead Wire:Standard 18 Housing:White ,Brown ,Grey Dim:11mm(dia.)*14.5mm Listings:UL ,CE,CUL Remark:A:Open or C:Closed& Open
Magnetic Contact MCR-1101Magnetic Contact MCR-1101
Model No.: MCR-1101MD
Magnetic Contact MCR-1101MD

Recessed Mounted Contact

Contact Type:Closed Loop Contact Rating :Breakdown Voltage 100v / Max.Switch Current 0.5A Opera. Gap:0.5Inch Magnet: Lead Wire:Standard 18 Housing:White ,Brown ,Grey Dim:11mm(dia.)*14.5mm Listings:UL ,CE,CUL Remark::A:Open or C:Closed& Open
Magnetic Contact MCR-1101MDMagnetic Contact MCR-1101MD
