PT-TK35 Series
Intelligence Pan-Tilt
- High Die-cast Aluminum construction, high
- temperature proof, fret proof
- Weatherproof design, protection grade IP66
- 360o Continuously
- Tilt range: +33o~-80o
- 0.01 Min.illumination,Auto pan function between
- 2 presets
- 128 presets. 6 tracks
- Dust-proof, antifogging, frost protection function
- OSD English operate menu, 2 channels alarm
- output
Description:
Model | PT-TK3518C | PT-TK3518B | PT-TK3523B | PT-TK3526B | PTTK3527B |
Image sensor | 1/4" CCD | ||||
Active pixels | 752(H)×582(V) | 752(H)×582(V) | 758(H)×592(V) | 752(H)×582(V) | 795(H)×596(V) |
Synchronization | Internal/Extrinsic | ||||
Video output | VBS 1.0Vp-p/75 ohms | ||||
White balance | Auto/Manual | ||||
Scanning frequency | 15.625KHz(H) 50Hz(V) | ||||
Horizontal resolution | 480TVL | ||||
S/N ratio | 50dB | 50dB | ≥50dB | ≥50dB | ≥50dB |
Electronic shutter | 1/3~1/10,000s | 1/3~1/10,000s | 1/3~1/10,000s | 1/3~1/10,000s | 1/50~1/10,000s |
Min illumination | 0.7Lux | 0.01Lux | 0.01Lux | 0.01Lux | 0.01Lux |
Focal length | F=4.1~73.8mm 18x | F=4.1~73.8mm 18x | F=3.6~82.8mm 23x | F=3.5~91mm 26x | F=3.6~98mm 27x |
Focal & Iris | Auto/Manual | ||||
Pan preset speed | 100°/s (wind speed low 50 mile/hour) | ||||
Tilt preset speed | 30°/s (wind speed low 50 mile/hour) | ||||
Pan range | 360° Continuously | ||||
Pan speed | 0°~40°/s | ||||
Tilt range | 90° | ||||
Tilt speed | +30°~-80°/s | ||||
Preset track | 128 presets, 6 tracks | ||||
Communication | Multi-protocol, Baud rate from 2400Bps to 19200Bps for optional, RS485 control | ||||
Relative humidity | 90% without agglomeration | ||||
IP grade | Ip66 | ||||
Power supply | AC24V/AC110V/AC230V | ||||
Power consumption | 70VA | ||||
Work temperature | -35oC~55oC | ||||
Weight | 10.5Kg |
