PT-TCB25 Series
Intelligence Pan-Tilt
- With infrared LED range up to 80 meters, It could
- catching image promptly at night
- Weatherproof design, high die-cast aluminum
- casing, protection grade Ip66
- Super shockproof, especially suitable for car
- surveillance
- 360o continuously rotation, upward angle
- up to 180o
- 6 cruising tracks, each cruising track has
- 16 preset positions, 128 preset positions
- Input voltage: DC10.5V~DC18V
Description:
Model | PT-TCB2518 | PT-TCB2523 | PT-TCB2526 | PT-TCB2527 | |
Image sensor | 1/4" CCD | ||||
Active pixels | 752(H)×582(V) | 752(H)×582(V) | 758(H)×592(V) | 752(H)×582(V) | |
Synchronization | Internal/Extrinsic | ||||
Video output | VBS 1.0Vp-p/75 ohms | ||||
White balance | Auto/Manual | ||||
Scanning frequency | 15.625KHz(H) 50Hz(V) | ||||
Horizontal resolution | 480TVL | ||||
S/N ratio | 50dB | ≥50dB | ≥50dB | ≥50dB | |
Electronic shutter | 1/3~1/10,000s | 1/3~1/10,000s | 1/3~1/10,000s | 1/50~1/10,000s | |
Min illumination | 0 Lux (LED Open) | ||||
Focal length | F=4.1~73.8mm 18x | F=3.6~82.8mm 23x | F=3.5~91mm 26x | F=3.6~98mm 27x | |
Focal & Iris | Auto/Manual | ||||
Pan preset speed | 100°/s | ||||
Tilt preset speed | 60°/s | ||||
Pan speed | 0°~80°/s | ||||
Tilt speed | 0°~40°/s | ||||
Pan range | 360° Continuously | ||||
Tilt range | +90°~-90° | ||||
Preset track | 128 presets, 6 tracks | ||||
Power supply | DC10.5V~DC18V(50VA) | ||||
IP grade | IP66 | ||||
Work temperature | -35oC~55oC | ||||
Shock | >=4G | ||||
Relative humidity | 90%without agglomeration | ||||
Communication | Multi-protocol, Baud rate from 2400Bps to 19200Bps for optional, RS485 control | ||||
Weight | 5Kg |
