Frequency:ISM 2,400 - 2,483MHz
Antenna: Omni-directional antenna
Display :2.5" LTPS-TFT LCD(Anolog) ;2.4G"LTPS-TFT LCD (Digtal)
Channel: 1-4 (Flip-type switch)
Intermediate Frequency: 480MHz
Frequency Stabilization: +/- 100KHz
Demodulation Mode: FM
Receiving Sensitivity:<=-85dBm
Video Output: 1Vp-p at 75 ohm, S/N>38dB
Audio Output: 1Vp-p at 600 ohm
Power:DC 5V
Operating Temperature: -10oC~+40oC
Operating Humidity: 85%RH
Dimension(WxLxH): 75x35x130mm
Weight:630g |
Frequency: ISM 2,400 - 2,483MHz
Imaging Sensor:1/3 inch OMNIVISION Color CMOS
Horizontal Resolution: 380TV Line
CMOS Total Pixels: 628 x 582 (PAL) / 510 x 492 (NTSC)
View Angles:View Angles: 62 degrees
Minimum Illumination: 1.5Lux / F1.5
Gain Control:Automatic
Transmission Power: 10mW
Consumption Current: 80 mA
Modulation Mode: FM
Bandwidth: 18M
Operating Range: 30m/100m (Obstructed / Unobstructed)
Power: DC 8V
Operating Temperature: -10oC~+40oC
Operating Humidity: 85%RH |
2.4GHz Wireless Color Camera with Built-in Microphone
2.4GHz Wireless 4-channel LCD Receiver
A/V Cable
8V Power Adaptor for Camera
Earphone
5V Power Adaptor for LCD Receiver |
