| Model No.:
ESP36PF9 |
 |
Mylar Speaker
Size DxH (mm):36X9
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.5
Resonant Frequency(Hz):650+/-20%
Frequency Range(Hz):Fo -3500
Sound Pressure Level(dB):86+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):16X5
Core Material:(mylar)Transparent
Fra
|
  |
|
| Model No.:
ESP40PF8.5 |
 |
Mylar Speaker
Size DxH (mm):40X8.5
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.5
Resonant Frequency(Hz):600+/-20%
Frequency Range(Hz):Fo -7000
Sound Pressure Level(dB):81+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):27X17X3
Core Material:(mylar)Transparent
|
|
|
|
| Model No.:
ESP23PF5 |
 |
Mylar Speaker
Size DxH (mm):23X5
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.3
Resonant Frequency(Hz):900+/-20%
Frequency Range(Hz):Fo -6500
Sound Pressure Level(dB):81+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):16X1.9
Core Material:(mylar)Transparent
F
|
|
|
|
| Model No.:
ESP50PF8.5 |
 |
Mylar Speaker
Size DxH (mm):50X8.5
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.5
Resonant Frequency (Hz):500+/-20%
Frequency Range(Hz):Fo -3000
Sound Pressure Level(dB):84+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):27X17X3
Core Material:(mylar)Transparent
|
|
|
|
| Model No.:
ESP16MA2.7 |
 |
Mylar Speaker
Size DxH (mm):16X2.7
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.3
Resonant Frequency(Hz):1300+/-20%
Frequency Range(Hz):Fo -8000
Sound Pressure Level(dB):78+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):6.5X0.5
Core Material:(mylar)Transparent
|
|
|
|
| Model No.:
ESP20MA3 |
 |
Mylar Speaker
Size DxH (mm):20X3
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.3
Resonant Frequency(Hz):900+/-20%
Frequency Range(Hz):Fo -5000
Sound Pressure Level(dB):80+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):8X1
Core Material:(mylar)Black
Frame Mate
|
|
|
|
| Model No.:
ESP27MA5 |
|
|
Mylar Speaker
Size DxH (mm):27X5
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.5
Resonant Frequency(Hz):650+/-20%
Frequency Range(Hz):Fo -7000
Sound Pressure Level(dB):84+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):9.5X1.5
Core Material:(mylar)Black
Frame
|
|
|
|
| Model No.:
ESP23MA3.7 |
 |
Mylar Speaker
Size DxH (mm):23X3.7
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.3
Resonant Frequency(Hz):1000+/-20%
Frequency Range(Hz):Fo -8000
Sound Pressure Level(dB):83+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):8X1
Core Material:(mylar)Transparent
F
|
|
|
|
| Model No.:
ESP29MA4 |
 |
Mylar Speaker
Size DxH (mm):29X4
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.5
Resonant Frequency(Hz):700+/-20%
Frequency Range(Hz):Fo -7500
Sound Pressure Level(dB):86+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):9.5X1.5
Core Material:(mylar)Black
Frame
|
|
|
|
| Model No.:
ESP30MA3.4 |
 |
Mylar Speaker
Size DxH (mm):30X3.4
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.3
Resonant Frequency(Hz):700+/-20%
Frequency Range(Hz):Fo -8000
Sound Pressure Level(dB):85+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):12.5X1.5
Core Material:(mylar)Black
Fra
|
|
|
|
| Model No.:
ESP32MA5 |
|
|
Mylar Speaker
Size DxH (mm):32X5
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.3
Resonant Frequency(Hz):700+/-20%
Frequency Range(Hz):Fo -5000
Sound Pressure Level(dB):84+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm):12.5X1.5
Core Material:(mylar)Transparent
|
|
|
|
| Model No.:
ESP36MA4.8 |
 |
Mylar Speaker
Size DxH (mm):36X4.8
Rated Impedance(ohm):8+/-15%
Rated Power (W):0.25
Max.Power (W):0.5
Resonant Frequency(Hz):550+/-20%
Frequency Range(Hz):Fo -7000
Sound Pressure Level(dB):89+/-3
Operating Temperature:-20 ~ +55
Magnet Size(mm)12.5X1.5:
Core Material:(mylar)Black
Fra
|
|
|
|
|
|
|
|
