Model No.:
141V-254 |
 |
2.54mm
Voltage rating:150VAC
Current rating:7Amps/way max.
Insulation resistance:5000M/500V
Wire range:20-26AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
141R-254 |
 |
2.54mm
Voltage rating:150VAC
Current rating:7Amps/way max.
Insulation resistance:5000M/500V
Wire range:20-26AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
142V-508 |
 |
5.08/7.62mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Insulation resistance:5000M/500V
Wire range:14-24AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
142R-508 |
 |
5.08/7.62mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Insulation resistance:5000M/500V
Wire range:14-24AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
143V-508 |
 |
5.08/7.50mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Insulation resistance:5000M/500V
Wire range:14-24AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
144R-500 |
 |
5.00/3.81/3.96/7.50mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Insulation resistance:5000M/500V
Wire range:14-20AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
144RA-500 |
 |
5.00/3.81/3.96/7.50mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Insulation resistance:5000M/500V
Wire range:14-20AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
206-500 |
 |
5.00mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Wire range:14-26AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
205-250 |
 |
2.50mm
Voltage rating:125VAC
Current rating:4Amps/way max.
Wire range:20-28AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
208-100 |
 |
10.00mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Wire range:14-26AWG
Operation temperature:-40 to+105
|
  |
|
Model No.:
207-750 |
 |
7.50mm
Voltage rating:300VAC
Current rating:10Amps/way max.
Wire range:14-26AWG
Operation temperature:-40 to+105
|
  |
|
|
