• Intelligence Pan-Tilt PT-TCB26 Series
  • Click:
PT-TCB26 Series

Intelligence Pan-Tilt

  • With infrared LED range up to 100 meters, It could
  • catching image promptly at night
  • Weatherproof design, high die-cast aluminum
  • casing, protection grade Ip66
  • With wiper
  • Super shockproof, especially suitable for car
  • surveillance
  • 360o Continuously rotation, upward angle up to 180o
  • 7 cruising tracks, each cruising track has 16 preset
  • positions, 128 preset positions
  • Input voltage: DC10.5V~DC18V
  • cart
  • Intelligence Pan-Tilt
  • Intelligence Pan-Tilt
Model PT-TCB2618 PT-TCB2623 PT-TCB2626 PT-TCB2627
Image sensor 1/4" CCD
Active pixels 752(H)×582(V) 752(H)×582(V) 758(H)×592(V) 752(H)×582(V)
Synchronization Internal/Extrinsic
Video output VBS 1.0Vp-p/75 ohms
White balance Auto/Manual
Scanning frequency 15.625KHz(H) 50Hz(V)
Horizontal resolution 480TVL
S/N ratio 50dB ≥50dB ≥50dB ≥50dB
Electronic shutter 1/3~1/10,000s 1/3~1/10,000s 1/3~1/10,000s 1/50~1/10,000s
Min illumination 0 Lux (LED Open)
Focal length F=4.1~73.8mm 18x F=3.6~82.8mm 23x F=3.5~91mm 26x F=3.6~98mm 27x
Focal & Iris Auto/Manual
Pan preset speed 100°/s
Tilt preset speed 60°/s
Pan speed 0°~80°/s
Tilt speed 0°~40°/s
Pan range 360° Continuously
Tilt range +90°~-90°
Preset track 128 presets, 6 tracks
Power supply DC10.5V~DC18V(50VA)
IP grade IP66
Work temperature -35oC~55oC
Shock >=4G
Relative humidity 90%without agglomeration
Communication Multi-protocol, Baud rate from 2400Bps to 19200Bps for optional, RS485 control
Weight 5Kg
