• Middle Speed Dome Md1 Series
  • Click:
Md1 Series

Middle Speed Dome

  • 6" indoor middle speed integrated dome system
  • Low noise design, smooth operation
  • Pan speed: 0o~80o/s
  • Tilt speed: 0o~40o/s
  • 64 preset positions
  • 6 cruising tracks, each cruising track has
  • 16 preset positions
  • Multi-protocol communication
  • BS485 data communication
  • 4-Alarm input
  • DC15V input
  • cart
Description:
  • Middle Speed Dome
  • Middle Speed Dome
Model MD1AC1P1 MD1AB1P1 MD1CB1P1 MD1DB1P1 MD1EB1P1
Image sensor 1/4" CCD
Active pixels 752(H)×582(V) 752(H)×582(V) 758(H)×592(V) 752(H)×582(V) 795(H)×596(V)
Synchronization Interna
Video output VBS 1.0Vp-p/75 ohms
White balance Auto/Manual
Scanning frequency 15.625KHz(H) 50Hz(V)
Horizontal resolution 480TVL
S/N ratio 50dB 50dB ≥50dB ≥50dB ≥50dB
Electronic shutter 1/3~1/10,000s 1/3~1/10,000s 1/3~1/10,000s 1/3~1/10,000s 1/50~1/10,000s
Min illumination 0.7Lux 0.01Lux 0.01Lux 0.01Lux 0.01Lux
Focal length F=4.1~73.8mm 18x F=4.1~73.8mm 18x F=3.6~82.8mm 23x F=3.5~91mm 26x F=3.6~98mm 27x
Focal & Iris Auto/Manual
Pan range 360° Continuously
Pan speed 0°~15°/s
Tilt range 90°
Tilt speed 0°~15°/s
Power supply DC12V
Power consumption 20VA
Work temperature 0oC~50oC
Preset 64(max)
Communication Multi-protocol, RS485
Weight 2Kg
