• PCB Terminal Block 135-635
  • Click:
135-635

PCB Terminal Block

6.35mm

  • Voltage rating:300VAC
  • Current rating:15Amps/way max.
  • Insulation resistance:5000M/1000V
  • Wire range:10-24AWG
  • Operation temperature:-33 to+120
  • Torque:4kg-cm/M3
  • cart
Description:
  • PCB Terminal Block
Contact:Brass Machined (metal housing) Terminal screw:Steel Galvanized and chormatized of Nickel plated or Tin plated (Standard option) Solder Pin:Brass with Tin plated Insulator body:Polyamide(Glass filled) (housing) (UL94V-0)
