HD3 Series

High Speed Dome

  • New version design
  • High Die-cast Aluminum Construction
  • Low noise design, OSD function, 128 preset
  • positions
  • 6 cruising tracks, each cruising track has 16
  • preset positions
  • 6 privacy zone masking
  • Coordinate display function
  • Soft-address edit function
  • Four pattern tours (each one with 120s memory)
  • Multi-protocol communication
  • RS485 date communication
  • 4-Alarm input and 1-Alarm output
  • AC24V input
  • cart
Description:
  • High Speed Dome
  • High Speed Dome
Model HD3AC1P1 HD3AB1P1 HD3CB1P1 HD3DB1P1 HD3EB1P1
Image sensor 1/4" CCD
Active pixels 752(H)×582(V) 752(H)×582(V) 758(H)×592(V) 752(H)×582(V) 795(H)×596(V)
Synchronization Internal/Extrinsic
Video output VBS 1.0Vp-p/75 ohms
White balance Auto/Manual
Scanning frequency 15.625KHz(H) 50Hz(V)
Horizontal resolution 480TVL
S/N ratio 50dB 50dB ≥50dB ≥50dB ≥50dB
Electronic shutter 1/3~1/10,000s 1/3~1/10,000s 1/3~1/10,000s 1/3~1/10,000s 1/50~1/10,000s
Min illumination 0.7Lux 0.01Lux 0.01Lux 0.01Lux 0.01Lux
Focal length F=4.1~73.8mm 18x F=4.1~73.8mm 18x F=3.6~82.8mm 23x F=3.5~91mm 26x F=3.6~98mm 27x
Focal & Iris Auto/Manual
Pan speed 0°~300°/s
Tilt speed 0°~120°/s
Pan range 360° Continuously
Tilt range 90°(180° auto overturn)
Power supply AC24V
Power consumption 15VA
Work temperature 0oC~50oC
Preset 128(max)
Relative humidity 90%without agglomeration
Communication Multi-protocol, RS485
Weight 2Kg
